PC 3800 Compact

Description

Compact lightweight solutions between one and four metre tonnes with real PALFINGER power

  • High value retention thanks to coating technology
  • Optimum protection thanks to internal oil ducts in the extention cylinders
  • Load holding valves prevent the crane boom from dropping
  • Extended range of applications thanks to the optional radio remote control and cable winch

Attributes

Max. lifting moment
3.7 mt
Max. lifting capacity
2000 kg
Max. hydraulic outreach
5.0 m
Max. manual outreach
7.1 m
Slewing angle
325°
Slewing torque
0.4 mt
Fitting space required (std)
445.00 mm
Width folded
0.77 m
Max. operating pressure
200 bar
Pump capacity
12 L/min.
Dead weight (std.)
238 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation Width
A

3.7

3.7

325

0.3

20.0

12

238

1630

775

445

B

3.6

5.0

325

0.3

20.0

12

262

1630

775

445

Brochures

PC Range
Download file
Download file
