PK 200002 L SH High Performance
Description
The long boom design is mainly intended for operations with high outreach
- High mobility due to the mounting on standard truck chassis
- Very stiff and light boom system thanks to new P-Profile
- Hydraulic lifting height of roughly 49 meter thanks to long boom design
- Additional applications with Power Link Plus
- High working speed thanks to double circuit control
- Special stabiliser concept with extendable rear stabiliser ram
- Maximum precision and safety due to AOS
- Maximum utilisation of the working range thanks to extended HPSC
- More efficiency with fly-jib due to DPS Plus
Attributes
Max. lifting moment
150.7 mt
Max. lifting capacity
40000 kg
Max. hydraulic outreach
25.6 m
Max. outreach (with fly jip)
47.9 m
Slewing angle
∞
Slewing torque with 2 gears
12.5 mt
Stabilizer spread (std)
10.4 m
Max. operating pressure
385 bar
Pump capacity
2x 120 l/min
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthBrochures
