PK 24.001 SLD 5
Description
- Maximum reliability due to PALTRONIC
- More lifting power due to A-HPLS
- Additional applications with Single Link Plus
- Shorter load cycle times due to High Speed extension
Attributes
Max. lifting moment
23.1 mt
Max. lifting capacity
6200 kg
Max. hydraulic outreach
14.9 m
Max. manual outreach
19.1 m
Slewing angle
400°
Slewing torque
2.3 mt
Stabilizer spread (std)
5.0 m
Fitting space required (std)
0.91 m
Width folded
2.54 m
Max. operating pressure
360 bar
Pump capacity
65 - 90 l/min
Dead weight (std.)
2260 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthA
22.7
8.2
400
2.3
36.0
65-90
2250
2310
2550
905
B
22.2
10.4
400
2.3
36.0
65-90
2410
2310
2550
905
