PK 250 TEC
Description
- More intelligent operation with PALTRONIC 180 control electronics
- Extra smooth control thanks to LX-6 control valve
- Very stiff and light boom system thanks to P-Profile
- More efficient and faster due to continuous slewing system
- High user friendliness due to in-house developed radio remote control PALcom P7
- Maximum utilisation of the working range thanks to extended HPSC
- More lifting power due to S-HPLS
- Practical and attractive due to Functional Design
Attributes
Max. lifting moment
23.5 mt
Max. lifting capacity
7100 kg
Max. hydraulic outreach
20.0 m
Slewing angle
∞
Slewing torque with 1 gear
2.5 mt
Stabilizer spread (std)
5.6 m
Fitting space required (std)
1.05 m
Width folded
2.55 m
Max. operating pressure
385 bar
Pump capacity
80 - 100 l/min
Dead weight (std.)
2525 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthA
22.8
8.4
∞
2.5
38.5
80-100
2570
2380
2550
1050
B
22.4
10.6
∞
2.5
38.5
80-100
2720
2380
2550
1050
