PK 42002 SH High Performance
Description
Thanks to Power Link Plus, the crane is extremly versatile. Crane work is possible even in difficult conditions.
- High value retention thanks to coating technology
- More comfort and safety due to Soft Stop
- Maximum utilisation of the working range due to HPSC
- More lifting power due to S-HPLS
- More efficient and faster due to continuous slewing
Attributes
Max. lifting moment
41.1 mt
Max. lifting capacity
15000 kg
Max. hydraulic outreach
21.0 m
Max. manual outreach
25.2 m
Slewing angle
∞
Slewing torque with 1 gear
3.8 mt
Slewing torque with 2 gears
5.0 mt
Stabilizer spread (std)
7.4 m
Width folded
2.51 m
Max. operating pressure
365 bar
Pump capacity
90 - 120 l/min
Dead weight (std.)
3851 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthA
40.2
7.7
∞
3.8 / 5.0
35.0
90-120
3851
2430
2510
1320
B
38.9
9.7
∞
3.8 / 5.0
35.0
90-120
4098
2430
2510
1320
