PK 580 TEC
Description
- More intelligent operation with PALTRONIC 180 control electronics
- Extra smooth control thanks to LX-6 control valve
- Very stiff and light boom system thanks to P-Profile
- More efficient and faster due to continuous slewing system
- High user friendliness due to in-house developed radio remote control PALcom P7
- More efficiency with fly jib due to DPS-C
- Maximum utilisation of the working range thanks to extended HPSC
- More lifting power due to S-HPLS
- Practical and attractive due to Functional Design
Attributes
Max. lifting moment
55.5 mt
Max. lifting capacity
20000 kg
Max. hydraulic outreach
21.2 m
Slewing angle
∞
Slewing torque with 2 gears
5.9 mt
Stabilizer spread (std)
7.8m
Fitting space required (std)
1.43 m
Width folded
2.55 m
Max. operating pressure
385 bar
Pump capacity
90 - 120 l/min
Dead weight (std.)
4670 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthA
54.7
7.9
∞
5.9
38.5
90-120
4670
2460
2550
1440
B
53.1
9.9
∞
5.9
38.5
90-120
4950
2460
2550
1440
