PK 8.501 SLD 3
Description
INTELLIGENT LIGHTWEIGHT DESIGN OFFERS AN OPTIMIZED MOUNTING CONCEPT
- More power in the hook due to Single Link
- Maximum reliability due to PALTRONIC
- Shorter load cycle times due to High Speed Extension
- Maximum utilisation of the working range due to HPSC
Attributes
Max. lifting moment
8.1 mt
Max. lifting capacity
5700 kg
Max. hydraulic outreach
11.8 m
Max. manual outreach
15.8 m
Slewing angle
400°
Slewing torque
1.0 mt
Stabilizer spread (std)
3.2 m
Fitting space required (std)
0.72 m
Width folded
2.32 m
Max. operating pressure
330 bar
Pump capacity
25 - 35 l/min
Dead weight (std.)
1050 kg
Lifting moment
Outreach
Slewing angle
Slewing torque (mt)
Pressure
Pump capacity (l/min)
Crane Weight
Crane Height
Crane Width
Installation WidthA
7.8
7.6
400
1.0
33.0
25-35
1140
2005
2300
720
B
7.6
9.7
400
1.0
33.0
25-35
1240
2005
2300
720
